LEWA ecosmart diaphragm metering pump

LEWA ecosmart®
diaphragm metering pump

LEWA ecosmart is an innovative, compact and multiplexing diaphragm metering pump at a smart price.

The ecosmart pumps are suitable for almost all fluids and are already being used in numerous industries. They offer the highest metering accuracy, safety and reliability and excellent efficiency, all packaged in a compact design. Flow rates of up to 2,000 l/h per pump head and a maximum flow rate of 80 bar are possible.

LEWA ecosmart®

Efficient, safe, cost-effective – the low-price diaphragm metering pump.

The LEWA ecosmart diaphragm metering pump offers the best price/performance ratio in its class and meters a wide variety of fluids with high precision. The hydraulically actuated metering pump features the patented sandwich diaphragm and the DPS diaphragm protection system.

The ecosmart ensures completely reliable operation and maximum safety for your production process and the environment. Thanks to its high energy efficiency, the life cycle and maintenance costs are extremely low.

With the ecosmart, you benefit from excellent LEWA quality at a reasonable purchase price. Order the ecosmart now at our Webshop. Choose one of various preconfigured versions and secure a discount of up to 20% and a delivery time of within just 10 business days.

In our augmented reality app orange showroom you will find a virtual presentation of the functionalities of LEWA ecosmart.

Good reasons for a LEWA ecosmart®

The LEWA ecosmart hydraulically actuated diaphragm pump does not just have a smart price, but smart technology as well.

High suction capability of LEWA process pumps

Unique suction capacity

The unique pumping speed of the LEWA ecosmart diaphragm metering pump distinguishes it from other pumps. With an absolute suction pressure of up to 0.1 bar abs., it not only provides a wide array of safe installation options. The operating costs for the entire system can also be lower than with other pumps.

Pumps with high metering accuracy

Highest metering accuracy

The flow rate of the ecosmart diaphragm metering pump can be set precisely by adjusting the rotation speed of the motor and through manual stroke adjustment. This allows you to meter various fluids for your processes to the precise defined quantities.

Safe metering of critical fluids with LEWA pumpheads

Absolutely safe startup

Starting up the metering pump is safe and easy: When the pump is not operating, a spring pulls the diaphragm into a safe position at all times. This allows us to guarantee maximum safety when starting up your system and optimum protection of the diaphragm.

Long lifetime

Low maintenance costs and a long service life

The ecosmart series features a long service life for all components and particularly low maintenance and operating costs. If regular maintenance intervals are maintained, our diaphragm pumps can operate for 40 years or more in your production process.

LEWA pumps are manufactured according to API standards

API 675‐Standard

The ecosmart series fulfills the internationally valid quality standard of the American Petroleum Institute API 675. In this standard, all requirements for a displacement pump in industrial settings are defined with respect to design, construction, performance and acceptance tests. We also adhere to additional, globally valid standards such as VDMA 24284, 24286‐10 and FDA guidelines.

Safety manometer of a LEWA pump

Safety and reliability in extreme operating states

For us, safety and reliability comes first: The pump is not subjected to damage, even after operating errors occur or in extreme operating states. We offer maximum protection for user and machine through built-in safety mechanisms - not only when excess primary pressure is present, but also when the discharge or suction line is closed.

Hermetically tight, leakfree diaphragm pumps

Patented sandwich diaphragm

Our patented LEWA sandwich diaphragm is not only extremely durable, but also well-protected. The LEWA DPS diaphragm protection system and a diaphragm monitoring system allow us to ensure that the diaphragm does not tear during operation and that the pump fluid is not contaminated.

Hermetically tight, leakfree diaphragm pumps

Hermetically sealed

Diaphragm pumps work without dynamic seals in the process fluid area. This forms a hermetically sealed working area. No emissions escape to the outside, and contamination of the fluid is impossible.

Pressure Valves

Integrated pressure relief valve

A pressure relief valve in the hydraulic part of the diaphragm pump prevents potential overload situations in operation. This valve is individually adjustable and can therefore be adapted to different operating situations.

Videos about LEWA ecosmart®

Options

Multiplex capability

Single drive units with vertically installed motor are space-saving. Alternatively, multiple drive units with identical or different output can be combined for pulsation reduction or recipe metering.

Customized valves

LEWA uses numerous special types of valves such as specially hardened valves for liquified gases or valves with minimal dead space for the food and pharmaceutical production.

Diverse connection geometries

Our pumps are equipped with all common connection geometries such as DIN standard, BASF's high-pressure standard, American ANSI, JIS, or your individual requirements. Customized configurations are possible.

Special design materials

If the process demands it, wetted parts such as pumps heads and valves will be made of special materials such as stainless steel 316/316L (1.4401/1.4404), Hastelloy or Duplex steel and PVC.

Integration into process control systems

The signal acquisition of process control systems is achieved analogously or digitally. Flow rate is adjusted via electric or pneumatic stroke adjustment, alternatively by motor drive (FU).

Complete documentation

In the process of documentation, we consider your requirements and provide inspection records, print samples, diagrams of output characteristics and registration papers on request.

Integrated pressure relief valve

An integrated pressure relief valve prevents potential overload situations. The valve is individually adjustable and can be adapted to different operating situations.

Flow meters

A pump is only as good as its control and regulation system. That's why we provide precise flow meters in different variations for accurate control.

Painting according to customer's requirements

You want your pump or system to be compliant with your corporate branding guidelines? No problem for us: we paint pumps, skids and systems in the colors you prefer.

Performance spectrum

With the combination of various pump heads and gear units, the inexpensive LEWA ecosmart diaphragm metering pumps cover a wide performance spectrum. We provide you with an energy-efficient pump for any application desired. Save space and weight through multiple arrangement of the pumps and meter multiple fluids at the same time with various pump heads.

Performance overview

Type Plunger
∅ [mm]
Qtheor [l/h] for each pump head,
full stroke length and stroke frequency n [rpm]
Pmax discharge
pressure [bar] 316L
Pmax discharge
pressure [bar] PVC
LCA 80109136163218
162.02.83.54.15.58012
183.64.96.27.49.98012
1116.89.311.613.918.68012
21411.115.118.822.630.28012
21716.322.327.833.344.55612

3

2227.437.346.555.874.63312
32844.360.475.490.3120.81912
43569.394.4117.8141.1188.81210
44299.8135.9169.6203.2271.877
Type Plunger
∅ [mm]
Qtheor [l/h] for each pump head,
full stroke length and stroke frequency n [rpm]
Pmax discharge
pressure [bar] 316L
Pmax discharge
pressure [bar] PVC
LCC 82112140168224
12228.138.347.957.576.65012
12845.462.177.693.1124.14612
23571.097.0121.2145.5194.02812
242102.2139.7174.6209.5279.31912
346122.6167.5209.4251.3335.01512
352156.7214.1267.6321.1428.11111
358195.0266.3332.9399.5532.699
466252.5344.9431.1517.3689.766
474317.4433.5541.9650.3867.044
482389.7532.3665.4798.51064.733
Type Plunger
∅ [mm]
Qtheor [l/h] for each pump head,
full stroke length and stroke frequency n [rpm]
Pmax discharge
pressure [bar] 316L
Pmax discharge
pressure [bar] PVC
LCD 114143171228
134183.0223.7279.5372.65012
138228.6291.9349.1465.44112
142279.3356.6426.4568.6

33

12
246335.0427.8511.5682.02712
252428.1546.6653.7871.62111
258532.6680.1813.21084.3169
366689.7880.61053.01404.1126
374867.01107.01323.81765.194
3821064.71359.31625.52167.373

Installation dimensions single pumps

LCALCCLCD
Type12341234123
Plunger ∅ [mm]6 - 1114 - 1722 - 2835 - 4222 - 2835 - 4246 - 5866 - 8234 - 4246 - 5866 - 82
L [mm]220230270285290305310365505545575
W [mm]355365375405440470490550610650680
H0.18KW [mm]436436436436_______
H0.37KW [mm]456456456456_______
H0.55KW [mm]527527527527_______
H3.00KW [mm]____720720720720___
H5.50KW [mm]________910910910

Installation dimensions multiplex pumps

LCALCCLCD
Type12341234123
Plunger ∅ [mm]6 - 1114 - 1722 - 2835 - 4222 - 2835 - 4246 - 5866 - 8234 - 4246 - 5866 - 82
W [mm]355365375405440470490550610650680
A [mm]600600600600780780780780850850850

ΔA [mm]

265265265265220320320320415415415
H  [mm]322322322322360360360360610610610

Single pump

Assembly dimensions of LEWA ecosmart pump

Multiplex pump

Pump head variants

We provide various pump heads for different applications. Here, the spectrum ranges from all-purpose variants to special designs for high temperatures, pressures or aggressive fluids.

Pump head M910

State of the art universal diaphragm pump head in stainless steel with PTFE sandwich diaphragm for maximum operational reliability.

TypeM910
Pressureup to 50 bar (LCC, LCD) up to 80 bar (LCA)
Flow rate2,000 l/h per pump head
Temperature-30/+120 °C
Viscosity100,000 mPa∙s
Material316L

Pump head M930

State of the art universal diaphragm pump head in PVC with PTFE sandwich diaphragm for maximum operational reliability.

TypeM930
Pressure12 bar
Flow rate2,000 l/h
Temperature-15/+60 °C
Viscosity

100,000 mPa∙s

MaterialPVC
